1. The excavator uses up to 20 percent less fuel than the 320F in similar applications.
2. Match the excavator to the job with power modes; let Smart mode automatically match engine and hydraulic power to digging conditions.
3. The advanced hydraulic system provides the optimum balance of power and efficiency while giving you the control you need for precise digging requirements.
4. Valve priority puts hydraulic pressure and flow where you command it to go for fast lightto medium load cycle times.
5. The engine meets U.S. EPA Tier 4 Final and EU Stage IV emission standards with an aftertreatment system that requires no operator input or downtime.
6. Add auxiliary hydraulics to do more work with a range of Cat attachments.
7. Product Link™ comes standard so you can remotely monitor machine health, location, hours, and fuel consumption on demand through the VisionLink® online interface.
Model | CAT 320 GC |
Operating Weight | 20400 kg |
Standard Bucket | 1 m3 |
Engine Model | Cat C4.4 |
Rated Power | 108 Kw |
Net Power | 107 kW |
Swing Speed | 11.6 r/min |
Maximum Digging Depth | 6710 mm |
Dimension | 9530*2980*2960 mm |
Net Power-ISO 9249: 17.6kW
Operating weight(kg): 3050
Maximum Digging Depth: 2950 mm
Net Power-ISO 9249: 15.7 kW
Operating weight(kg): 1775
Maximum Digging Depth(mm): 2540
Net Power-ISO 9249: 15.7 kW
Operating weight(kg): 2262
Maximum Digging Depth(mm): 2570
