1. Equipped with YC6J125Z-T20 engine.
2. Short wheel base, small turning radius and flexible serve for operation in narrow space.
3. Minimum ground clearance is up to 430mm with excellent passing performance
4. Adopted a large vision, all closed damping cab, comfortable operation environment
5. Four-wheeled driving, low-pressure, wide-base, off-highway tires with good performance of passing
|
Parameter
|
Foton lovol FL956H
|
|
Operating Weight(kg)
|
16970
|
|
Bucket Capacity(m3)
|
3.3
|
|
Rated Load(kg)
|
5500
|
|
Max. Traction Force(kN)
|
160
|
|
Max. Breakout Force(kN)
|
165
|
|
Max. Gradeability(°)
|
30
|
|
Dumping Angel(°)
|
44
|
|
Lifting Height(mm)
|
5645
|
|
Max. Dumping Height(mm)
|
3100
|
|
Dumping Reach(mm)
|
1160
|
|
Mini. Ground Clearance(mm)
|
440
|
|
Wheel Tread(mm)
|
2150
|
|
Wheel Base(mm)
|
3300
|
|
Mini. Turning Radius of Outside Tire(mm)
|
7020
|
|
Dimension(L×W×H mm)
|
8360×2980×3380
|
|
Engine Model
|
Weichai WD10G220E24
|
|
Cylinder No.-Cylinder Dia.×Stroke(mm)
|
6-126*130
|
|
Max. Torque (N·m)
|
900
|
|
Rated Power(kW)
|
162
|
|
Rated Speed (rpm)
|
2000
|
|
Transmission Type
|
Mechanical shifting planetary
|
|
No. of Gears
|
Front2back1
|
Net Power-ISO 9249: 92 kW
Operating weight(kg): 10300
Rated load capacity (kg): 3000
Bucket Capacity(m3): 3.3
Operating weight(kg): 17440
Rated load capacity (kg): 5500
Bucket Capacity(m3): 3.3
Operating weight(kg): 16970
Rated load capacity (kg): 5500
